The RCF HDL26-A is an ultra-compact bi-amped two-way active touring system for small and medium-sized events, both indoors and outdoors. Due to the advanced transducer design and the 2000W Class-D amplifier, among the best in its class, it is capable of an extended bottom-end and a pristine sound for a wide range of applications, alone or in RDNet managed line-array configurations. The HDL 35-AS is the ideal flyable bass complement for the HDL 26-A array system. The acoustic beauty of symmetry The symmetrical design of the cabinet produces identical left and right coverage of 100°x10°. Component positioning and the special DSP crossover of the HDL 26-A ensures constant directivity, reducing spots of break up or attenuation. The front baffle provides: Coplanar woofers Controlled LF dispersion with hybrid-bandpass design Central space to host the HF waveguide Advanced design The integrated fittings are both easy to use and reconfigurable, allowing the system engineer to create J-shaped and spiral arrays starting at 1° angle. The hardware is designed for easy and fast setup. Up to 16 HDL 26-A modules can be fastened on a single flybar. The heavy-duty front grille is powder coated. A special transparent-to-sound foam backing inside helps to further protect the transducers from dust. For weatherproof capabilities, a rain cover is available. New perspective on linearity RCF speakers are designed using a proprietary and advanced digital FiR technology, conceived to deliver transparent sound, absolute clarity, and perfect imaging to the listener. The special FiRPHASE filters allow for coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies in the system. Legendary transducers The RCF HDL 26-A features state-of-the-art RCF transducers with neodymium magnets. RCF’s experienced engineering teams have specially developed and matched each component — starting from the power supply through the input board to the amplifiers and transducers right up to the complete HDL 26-A System. High frequencies High-performance RCF ND840 3.0-inch diaphragm titanium compression driver 1.4-inch exit throat 750 Hz Crossover Point Low frequencies 2 X 2.0” voice coil neodymium 6” woofers Low frequencies handling down to 55 Hz Water resistant fiber doped cone Polycotton M-roll surround Hypervented magnetic structure Specification: Frequency Response – 55 Hz ÷ 20000 Hz Max SPL @ 1m – 133 dB Horizontal coverage angle – 100° Vertical coverage angle – 10° Compression Driver – 1 x 1.5” neo, 3.0” v.c Woofer – 2 x 6.0” neo, 2.0” v.c Total Power 2000 W Peak, 1000 W RMS High frequencies 600 W Peak, 300 W RMS Low frequencies 1400 W Peak, 700 W RMS Cooling – Convection Connections -Powercon IN/OUT Height – 237 mm / 9.33 inches Width – 470 mm / 18.5 inches Depth – 377 mm / 14.84 inches Weight – 13.5 kg / 29.76 lbs
